Wheel Load Measuring System (Axle Load Measurement System)

Wheel Load Measuring System

The Wheel Load Measuring System is designed to measure wheel and axle loads applied to railway vehicles with high precision. By accurately analyzing load distribution, the system helps prevent derailment risks, enhance operational safety, and improve maintenance efficiency.

Built with a sensor-based measurement structure and advanced digital data processing technology, it enables systematic data management and analysis.

• KEY FEATURES

• Sensor-Based Measurement Structure
  Rail-embedded continuous measurement system

• Digital Data Integration
  Real-time display and external system connectivity

• Excellent Installation Adaptability
  Installation without rail cutting

• High Durability
  Reinforced structure for long-term operation

• KEY ADVANTAGES

• Enhanced Railway Safety
  Detects wheel load imbalance in advance

• Portable & Easy Installation
  Flexible operation across various maintenance environments

• High Measurement Accuracy
  ±1% precision for reliable diagnostics

• Multi-Component Measurement
  Applicable to car body, bogie, and axle loads

• Improved Work Efficiency
  Position guidance system for accurate measurement setup

---

---

• TECHNICAL SPECIFICATIONS

  (Subject to Customization)

• Base Size: ≤ 600 mm

• Unit Weight: ≤ 60 kg

• Protection Grade: IP67 (Water & Dust Resistant)

• Maximum Measured Load: 15,000 kg per wheel

• Accuracy: ±1%

• Minimum Measurement Unit: 20 kg

• Control System: Computer & Controller

• Software: Dedicated measurement software included

• APPLICATIONS & BENEFITS

• Railway vehicle inspection and maintenance

• Early detection of derailment risks

• Applicable to high-speed rail, metro, conventional, and freight trains

• Integrated software for data management and analysis

• CUSTOM MANUFACTURING

  The system can be customized according to vehicle type, axle load range, installation environment, and operational requirements. Dedicated engineering design is available to match specific railway maintenance facilities.

• INQUIRY

  For specification discussions, customization requests, and technical consultations regarding the Wheel Load Measuring System, please contact us at any time.
